Note: This is the second of a series covering Kubernetes resource management and optimization. In this article, we explain Kubernetes requests and limits. You can revisit part one explaining Kubernetes resource types here.
Kubernetes provides a shared pool of resources that it allocates based on how we configure our containerized applications. The allocation process occurs when a scheduler places pods on nodes. After checking the container’s resource configuration, the scheduler selects a node that can guarantee the availability of the resources specified by the container configuration. It then places the container’s pod on the suitable node. Typically, this ensures that the deployed microservice will not encounter a resource shortage.
However, some workloads may require more resources than the containerized application has been configured to use. Without a means to restrict the resources that an application can request to use, our application can incur any combination of excessive costs, wasted resources, poor application performance and even application failures. Therefore, it is essential to implement a system of boundaries to prevent resource waste and costly failures.
This is why resource requests and limits are vital components of the Kubernetes environment.
A request refers to the resources that must be reserved for a container. Including a resource request ensures that the container will receive at least what is requested.
When a container includes a resource request, the scheduler can ensure that the node to which it assigns the pod will guarantee the availability of the necessary resources.
A limit is the maximum amount of resources that a container is allowed to use. When we do not configure a limit, Kubernetes automatically selects one. Therefore, when a limit is poorly configured — whether by a developer or Kubernetes — we can experience any number of unpleasant and costly consequences.
These consequences, which we will explore later in greater depth, include unnecessarily high cloud costs and poor performance due to CPU throttling and out-of-memory (OOM) errors.
While there are several types of resources, in this article we’ll focus on CPU and memory. We’ll refer to these resources collectively as “compute resources.”
In the Kubernetes environment, CPU represents overall processing power. We measure it in Kubernetes CPUs, where one CPU unit represents one physical CPU or virtual core.
To accommodate a wide variety of application types, we can express CPU measurements with great precision — down to 1/1000th of a CPU or core. If, for instance, we want to request 0.5 of a CPU, we should express it as 500m — where m represents millicores:
cpu: "500m"When creating a container, we can use resources:requests and resources:limits in the manifest to specify CPU resources:
apiVersion: v1
kind: Pod
metadata:
name: example-pod
namespace: example-namespace
spec:
containers:
- name: example-name
image: repo/example-image
resources:
limits:
cpu: "500m"
requests:
cpu: "250m"
In the example above, we’ve specified the container’s requested CPU as 250m and the limit as 500m. This means the processing power that will be reserved for the container is 250m. Furthermore, if a process requires more than 250m, it can access the additional CPU resources that the scheduler will ensure are available on the node — up to the 500m limit.
Memory resources are measured in bytes and can be expressed as fixed-point numbers, integers, or power-of-two equivalents. We will use the most common type of expression — the power-of-two equivalent, Mi. This represents a Mebibyte, or 220 bytes.
For instance:
memory: “258Mi”Just as we did with CPU, we can use resources:requests and resources:limits in the manifest to specify memory resource requests and limits.
Let’s add a memory request and limit to the manifest below:
apiVersion: v1
kind: Pod
metadata:
name: example-pod
namespace: example-namespace
spec:
containers:
- name: example-name
image: repo/example-image
resources:
requests:
memory: "64Mi"
cpu: "250m"
limits:
memory: "128Mi"
cpu: "500m"
A container created using this manifest will have 64Mi of memory guaranteed and reserved. If a process requires more than that and it is available on the node, it can access the additional amount as long as it doesn’t surpass the 128Mi limit.
Moreover, if a container specifies its compute resource limits but doesn’t specify the resource requests, then Kubernetes will automatically configure the requests to equal the limits.
Requests are a critical component of pod scheduling, a task executed by Kube-scheduler.
Scheduling is the process of matching pods to the right nodes before the Kubelet runs them. This process accounts for the pod’s resource requirements and the free resources on available nodes. In our example — and as is often the case — the pod’s resources include the container’s required resources and the resources required by the pod itself.
In a cluster, nodes that have the resource capacity to accommodate new pods are called feasible nodes. The scheduler works to evaluate these nodes and select the optimal one for the pod. The assessment process requires the scheduler to consider several factors, including:
The pod is then placed on the selected node. Then, the Kubelet starts the container inside the pod by passing the container’s memory and CPU limits and requests to the container runtime.
If a process inside a container exceeds the requested memory and its node runs out of memory, the pod hosting the process will likely be evicted.
However, it is important to note that there is a sequence to follow when evicting pods. It all depends on the pod’s quality of service.
When a pod is created, it receives an assigned quality-of-service (QoS) class depending on its resource specifications. There are three classes of QoS:
QoS is important in determining which pods the Kubelet can evict from a node if it runs out of computing resources. An eviction occurs when a node wants to reclaim some resources to ensure the continued operations of the remaining pods.
The Kubelet will evict BestEffort pods before Burstable pods. It will then evict Burstable pods before guaranteed pods.
If we fail to set resource limits and requests, Kubernetes will automatically set them for us. This might sound convenient, but Kubernetes aims to ensure that the application doesn’t fail. As a result, it will assign unreasonably generous limits.
For instance, if we do not specify a request or limit for a cluster that only requires 250m of CPU resources, Kubernetes might set a CPU request of 900m. This will bloat the resource requirements of our cluster, making it excessively expensive to run.
Additionally, if Kubernetes unnecessarily reserves large amounts of resources, we might encounter frequent OOM errors.
Furthermore, when the evicted pods accumulate, our clusters become untidy. Even when the evicted pods no longer consume the nodes’ resources, they require extra resources from within the Kubernetes environment.
CPU throttling is another consequence of failing to set — or improperly setting — CPU limits. When we specify a CPU limit, Kubernetes attaches a timeframe within which that CPU capacity is allowed. If the container exceeds the limit before the cycle ends, it must pause and wait for the next cycle to begin before it can continue executing. This can lead to significant increases in response time.
Accuracy is paramount in determining requests and limits. Whereas setting the limit too high results in wasted resources, setting it too low dramatically increases the potential for CPU throttling.
When performed correctly, setting compute resource requests and limits results in smooth and fast performance at a low cost. But getting it right can be tricky.
Therefore, it can be extremely beneficial to employ a resource optimization solution that can account for application performance when providing recommendations. One such solution is StormForge.
StormForge Optimize Live uses machine learning to determine the optimal configurations automatically. From its recommended options, we can choose CPU limits that optimize our clusters for performance or cost, ensuring that we can align our Kubernetes environments to our business goals. Depending on our choice, StormForge acts in one of the following ways:
The more resources a Kubernetes cluster consumes, the more expensive it is to run. If we allocate minimal resources to save on cost, we face poor performance and frequent, costly OOM errors.
By properly specifying our compute resource requests and limits, we can minimize overspending, optimize performance, and ensure the most efficient use of our Kubernetes resources. However, trying to determine the optimal balance can be arduous.
StormForge reduces the labor with an automated, AI-driven solution that aligns your configurations to the needs of your business. You can try it for free to experience just how easy it can be to generate the best performance with the greatest cost efficiency.
Stay tuned for future articles in this series where we’ll explain how to set optimization goals and how to tackle some of the most difficult optimization challenges.
This post was originally published on The New Stack.
You can try Optimize Live for yourself with a free trial, or play around in our sandbox environment.
